DV - 6 Sensor Tubes

1 Torr to 0.001 Torr (133.3 to 0.133322 Pa) vacuum measuring sensor

Teledyne Hastings, manufacturer of the original DV-4, DV-5, and DV-6 thermocouple vacuum gauge tubes, produces vacuum measurement equipment with exceptional stability, accuracy, and reliability under the most demanding conditions.

The Teledyne Hastings’ DV-6 series thermocouple vacuum gauge tube/sensor can be paired with a variety of meters or controllers in the DV series to provide reliable, cost effective measurements in a variety of applications. The robust, easy to install gauge system translates  a thermoelectric voltage to a vacuum pressure based on the density of the gas. The thermocouple gauge tube/sensor, DV-6,  is fully compensated for temperature and rate of temperature change with no suspended weld to an external heater.

The gauges are calibrated for nitrogen or air, but conversion factors for other gases are available from the factory.  The thermocouple gauge or controller does not require recalibration when thermocouple gauge tubes are replaced further decreasing process down time. However, our DB-20 reference tube is available to confirm meter/controller performance. Installation accessories are also available from the factory  to support your installation needs.  One less thing to worry about, when performance matters!

With a wide range of meter, fitting, relay and output options the DV-6 series can support a variety of applications. ​

​Combinable measuring instruments

​DAVC

VT/CVT

CVT/DCVT

HPM 4/5/6

Applications and Industries

  • Semiconductor Process

  • Cryogenic Tank

  • Plasma Coating

  • Load Lock

  • Laboratory
